LA-300 · SPORTS AND STADIUMS
Modular sports floodlight
From 400 to 1,200 W, available in 5 wattages. Control: 1-10 V, dimming down to 10%.
- Wattage
- 400 – 1,200 W
- Max efficacy
- 185 lm/W
- Protection
- IP66 · IK10
- Warranty
- 5 years
- Lifetime
- L70B10 > 108,000 h
- Dimming
- 1-10 V
Specifications
400 W600 W800 W1,000 W1,200 W
| Input voltage | 100 – 277 V AC · 200 – 277 V AC · 200 – 480 V AC · 277 – 480 V AC |
|---|---|
| Control and options | 1-10 V, dimming down to 10% |
| Colour temperature | 2,700 – 6,500 K |
| Colour rendering | CRI 70 or 80 |
| LED source | LED 3030 / 5050 |
| Optics | Beam angles 40°, 60°, 120° |
| Surge protection | 10 / 20 kV |
| Lifetime | L70B10 > 108,000 h |
| Net weight | 12.6 – 23.8 kg |
| Warranty | 5 years, extendable to 10 years on request |
| Certifications | On request, per series and wattage |
Maximum values for the series, measured at 25 °C, ±5% tolerance. Flux and efficacy vary with wattage, optics and colour temperature: see the datasheet.
Documents
Datasheet LA-300PDF · on requestPhotometric filesIES · LDT · on requestInstallation guidePDF · on requestDeclaration of conformityPDF · on request
